Good PCB & PCBA Manufacturer Electronic PCB & PCBA Manufacturing

FOB Reference Price:Get Latest Price
$0.10 - $1.36 / Piece | 5 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Model Number:
PCBA-003
Stack Up:
4-Layer PCB
Surface Treatment:
HASL-LF
Finish Copper:
1 OZ
Application::
Consumer
Name:
Other PCB & PCBA
Brand Name:
Wonstron
Base Material:
FR-4
Copper Thickness:
1oz
Board Thickness:
1.6mm
Min. Hole Size:
0.20mm
Min. Line Width:
0.1mm
Min. Line Spacing:
0.1mm
Surface Finishing:
HASL Lead Free
Supply Ability
Supply Ability:
10000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
Vacumn packing for bare board, standand cartons outside for shipping of PCB prototype .
Port
shenzhen
Lead Time :
5-8 days
Product Description

The PCB is UL certification rated 94v-0 standard. 94v-0 standard  rated PCBs are certified for fire

resistance and self-extinguishing characteristics.

Files and Requirment for PCB,PCBA quotation:
A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.

A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements

Electronic component

a:Resistance  b:Capacitance   c:Diode  d:Transistor  e:Inductance   f:Crystal   g:Integrated circuit   h:Sensor
i:Switching devices  j:Display device  k:Connector

  We provide full BOM sourcing including all kinds of components, i.e. connectors, cables, plastic mold,
LED lighting, etc. Most of them are of competitive prices from China.

PCBA-004-06
Our Manufacture Capacity



Item

Mass Production

Max Stencil Size

1560mm*450mm

Min SMT Package

 0201

Min IC Pitch

0.3mm

Max PCB Size

1200mm*400mm

Min PCB Thinkness

0.35mm

Min Chip Size

001005

Max BGA Size

74mm*74mm

BGA Ball Pitch

1.0-3.00

BGA Ball Diameter

0.2 - 1.0mm

QFP Lead Pitch

0.2mm-2.54mm

SMT Capacity

2 million points per day







Production Lead time





Item/Lead Time

 Samples

Mass Production

Components

1-2 days

5-10 days

SMT

1-2 days

5-10 days

Delivery

3-5 days

5-20 days

*There will be exception for components with extremly long lead time.



Buying Guides
Our Services

 our service

Company Information

Thanks for visiting Wonstron Electronics Co., Ltd!



We are professional PCB manufacture with SMT lines in house. We were founded by a team with more than 20 years in the field. We own abundant experiences for serving overseas customers from industrial automatic control, communication, medical, Auto and consumer electronics,etc. We test our product strictly to guarantee the quality to our customers. We accumulate high reputation during our cooperation.You will achieve following value-added services when you cooperate with us:

  1. One-stop PCB/PCBA Service
  2. Optimizing your PCB design during production
  3. Satisfied quality with competitive prices
  4. Instant response in both quotation and delivery
  5. Increase your business with our powerful support

Our Work lines



Packaging & Shipping


We can offer DDU express by DHL, Fedex, TNT, UPS or by air and BY sea for big quantity. We have our own forwarder whose can offer competitive prices to safe your logistic cost.
